Description
The built‑under hot water cylinder is engineered for installation in tight spaces such as pitched‑roof voids, under staircases, or any location where a standard floor‑standing cylinder cannot be accommodated. Its compact form makes it particularly suitable for pairing with wall‑hung boilers.
A generously sized heat‑exchanger coil extends right down to the base of the cylinder, delivering excellent heat transfer and fast warm‑up performance. The side‑mounted inspection flange provides easy access for maintenance and cleaning, and can be fitted with an electric immersion heater if required.
The cylinder is insulated with OEG’s advanced vacuum insulation, which offers significantly lower heat losses compared with conventional cylinders on the market, ensuring maximum efficiency in restricted‑space installations.
Tank Sizes and Weights
80L 45kg 620mm x 610mm
120L 65kg 830mm x 610mm
150L 75kg 985mm x 610mm
200L 92kg 1245mm x 610mm
